1. Class leading speed, up to 42,000 cph
2. 0201* ~ 74mm×74mm / 50mm×150mm
3. Wide component range
4. Optimum line balance and highest throughput
5. Newly developed “Takumi Head” with changing recognition sensor height
6. JUKI’s laser centering technology is fast, accurate and reliable for a wide range of parts.
Specification of JUKI SMT Line Machine
Placement Machine
| Item/Model | YSFX-3RAL | YSFX-3RAXL | ||
| Board size | L size(410x360mm) | YES | NO | |
| L-Wide size(510x360mm)*1 | YES | NO | ||
| XL size(610×560mm) | NO | YES | ||
| Applicability to long PWB*1 | 800×360mm | 800×560mm | ||
| Component height | 6mm | YES | ||
| Component size | Laser recognition | 0402(01005) ~ 33.5mm×33.5mm | ||
| Placement speed (chip) | Optimum | 0.040Sec. / chip(90,000CPH)*2 | ||
| IPC9850 | 66,000CPH*2 | |||
| Placement accuracy | Laser recognition | ±0.05mm(±3σ) | ||
| Feeder inputs | Max.240 in case of 8mm tape (on a Electric double tape feeder) | |||
*1 L-Wide size , Applicability to long PWB is optional.
*2 This speed does not apply to XL board size.
Customers Factory
